Alvin Drafting Small Ellipse Guide Template
Model Number:
TD333
Drawing ellipses has never been easier than with this ellipse template.
Features:
- 79 ellipse cutouts with centering lines, from 1/8" to 1-3/4"
- Projections of 15, 30, 45, 60 degrees
- 15 degree: from 3/16" to 1-5/8"
- 30 degree: from 1/8" to 1-1/2"
- 45 degree: from 1/8" to 1-3/4"
- 60 degree: from 1/8" to 1-5/8"
- Fraction and millimeter designations
- Pencil allowance on all openings for 0.5mm pencil lead
- Non-glare, odor-free, flexible, and durable translucent plastic
Product Dimensions:
- Outside Dimensions: 8½" x 11" x .030"
- Product Weight: 0.13 lbs.
