Retail: $53.77
    Price: $34.70
    You Save: $19.07 (35.5%)
    SIZE:

    Quantity:

    Model Number: PA305
    Estimated Delivery Time:
    Alvin Drafting Wood Pantograph

    Model Number: PA305

    Unlock the power to create enlarged or reduced drawings up to 10x scale with the Alvin Wood Pantograph. Crafted with arms from seasoned hardwood and chromed steel hardware, it ensures durability and precision. Complete with a table clamp and four spare leads, this tool is your go-to for precise scaling—just note it's not intended for 1:1 ratios.

    Features:
    • Arms made from seasoned hardwood and chromed steel hardware and components.
    • Includes table clamp and four spare leads.
    • Not designed for 1:1 ratio.
    • Available in three sizes: 18" (20 ratios), 21" (25 ratios), 24" (30 ratios)

    Product Dimensions:
    • Outside Dimensions: 18" to 24"
    • Product Weight: lbs.
    Ask a Question. We would love to help!

    Alvin Drafting Wood Pantograph

    Overall Customer Rating of 4 Reviews:
    review-star review-star review-star review-star review-star
    New Hampshire

    ALVIN WOOD PANTOGRAPH 24 INCH

    Appearance:
    review-star review-star review-star review-star review-star
    Quality:
    review-star review-star review-star review-star review-star
    Price/Value:
    review-star review-star review-star review-star review-star
    Pros:
    Cons:
    • board clamp should be wider
    <p>Had a plastic pantograph and it was unstable hard to work with.</p>
    <p>Alvin Pantograph is easy to work with and is ridged, stable, and allows good control. </p>
    <p>24" length gives great working range for copying photos to canvas for painting.</p>
    <p>The hold down board clamp should have a wider clamping range. I as able to work around it but it is something that should be looked into.</p>

    California

    Doesn't work, waste of money

    Appearance:
    review-star review-star review-star review-star review-star
    Quality:
    review-star review-star review-star review-star review-star
    Price/Value:
    review-star review-star review-star review-star review-star
    Pros:
    • concept
    Cons:
    • quality
    • disfunctional
    The instructions for set-up and use are clear enough to follow. Unfortunately, the clamp is too small to fit on the table; the whole apparatus is clunky, the enlarged image doesn't resemble the original image in any manner. Huge disappointment. This product should not be available for sale. Waste of time, waste of money.

    Fort Valley Va

    Wood pantograph

    Appearance:
    review-star review-star review-star review-star review-star
    Quality:
    review-star review-star review-star review-star review-star
    Price/Value:
    review-star review-star review-star review-star review-star
    Pros:
    Cons:
    The pantograph came quickly.
    The instructions were clear. I am an artist and was enlarging images of my own on a canvas. As the canvasses were 1.5 inches off the table, I had to construct a new anchor point for the pantograph, so I could work on the higher images. After we got that figured out, transferring the images was easy, as the pantograph was meant to be used.

    I will have to keep playing around with ratios, but even that became familiar after a while. The pantograph works just fine. I greatly appreciated that it was made in the USA and sold here.

    Thanks, good job!

    Sebastian, FL

    Pantograph

    Appearance:
    review-star review-star review-star review-star review-star
    Quality:
    review-star review-star review-star review-star review-star
    Price/Value:
    review-star review-star review-star review-star review-star
    Pros:
    Cons:
    I had one of these instruments years ago. It has long since disappeared.
    I am now a working leathersmith and am currently doing a series of family Coats of Arms.
    I haven't used it yet but am familiar with it's function. Many of the Coats of Arms I research are small and the finished product goes into a 10"x12" shadow box frame, so, I'm sure, it will do the enlarging task with no issues.
