Electrical Symbols Template
Pacific ArcNOW: Inc. TaxWAS: Inc. TaxNOW: $5.40WAS:The Pacific Arc Template Guides are the ideal perfect guide for geometry, drawing, plans, and sketches. Made of a strong translucent green plastic, these templates are perfect for use on any surface... -
Electric/Electronic Template
Alvin DraftingNOW: Inc. TaxWAS: Inc. TaxNOW: $9.20WAS:(3)
This electrical design template features drawing symbols for electrical controls in machinery and automation circuits.Features: Assorted cutouts and symbols for electrical and electronic... -
Standard Electrical Symbol Template
RapiDesignNOW: Inc. TaxWAS: Inc. TaxNOW: $22.45WAS:(3)
Size: 5" x 8" x .030".
Description
Contains a comprehensive set of three templates conforming to ANSI Y32.2. Size: 7¾" x 5" x .030"; 8" x 4-3/8" x .030"; 8" x 3¾" x .030".
