Shop ellipse templates for drafting, isometric drawing, engineering, architecture, technical illustration, and design work. These templates help create clean, accurate ellipses in common drafting angles and sizes without relying on freehand drawing.
Filter By
Products List
- Product
- Qty in Cart
- Quantity
- Price
- Subtotal
-
75° Ellipse Template
Pickett$16.00Pickett ellipse templates are suitable for many drafting needs. Manufactured with drawing risers that separate the template underside from the drawing surface to ensure clean, smear-free results. ... -
75° Ellipse Template PK
Pickett$9.75Pickett ellipse templates are suitable for many drafting and drawing needs.Features:27 Sizes: 1/8" to 2"Built-in risers and smooth apertures to reduce smudged lines for engineering, drafting and... -
80° Ellipse Template
Pickett$11.50Pickett ellipse templates are suitable for many drafting needs. Manufactured with drawing risers that separate the template underside from the drawing surface to ensure clean, smear-free results. ... -
80° Ellipse Template PK
Pickett$9.75Pickett ellipse templates are suitable for many drafting and drawing needs.Features:27 Sizes: 1/8" to 2"Built-in risers and smooth apertures to reduce smudged lines for engineering, drafting and... -
Ellipse Master Combo Template
Pickett$17.20Contains four projections of 15 30 45 and 60. Size range from 1/8" to 1¾". Size: 8-11/16" x 12" x .030". -
Ellipse Master Combo Template
RapiDesign$20.15Contains 79 ellipses with projections of 15°, 30°, 45° and 60° 15° projections from 3/16" to 1-5/8", 30° From 1/8" to 1½", 45° from 1/8" to 1 �", and 60° from 1/8" to 1-5/8". Size: 11" X 8½"... -
Ellipse Template
RapiDesign$16.85Contains 60 ellipses in four projections of 25 35 45 and 60. Size range from ¼" to 13/8". Size: 5" x 10 ¼" x .030". -
Even Ellipse Master Template
Alvin Drafting$8.40This template is great for architects, builders, interior designers, engineers, students, design colleges. Sizes range from 0.25 inch to 1.5 inches, allowing for much more precise and consistent... -
Even Ellipse Master Template-1764403125
Pacific Arc$6.00This ellipse template is designed for precision and versatility, making it an essential tool for students, drafters, and architects. Featuring 79 ellipses with five-degree projections and built-in... -
Isometric Ellipse Guide
Alvin Drafting$6.80Features: 27 isometric ellipse cutouts, with centering linesSizes 1/8" to 2"Fractional, decimal, and millimeter designationsEdge scale graduated in inchesPencil allowance on all openings for 0.5mm... -
Isometric Ellipse Master Template
Pickett$12.55Contains 60 ellipses in four projections of 25 35 45 and 60. Size range from ¼" to 1½". Size: 5" x 11" x .030". -
Isometric Ellipse Template
RapiDesign$23.50Contains 12 isometric ellipses with axes from 1½" to 2" in increments of 1/8" and from 2" to 7" increments of ¼".Size: 6-1/16" x 9-7/8" x .030". -
Isometric Ellipse Template
Timely Templates$7.70Contains 40 ellipses from 3/32" to 1-9/16". Size: 6½" x 10½" x .020". -
Isometric Ellipse Template ALV
Alvin Drafting$6.90This isometric ellipses template is ideal for planning, drafting, drawing and other craft projects.Features:39 ellipse cutouts with centering lines from 1/8" to 1-3/4"Isometric projection of 35... -
Isometric Ellipses
Pickett$12.80Pickett Templates - for all your drawing template needs. Features: Includes ellipses at 35 degree 16' projection Sizes for 1/8 to 1-9/16 inches Built-in risers and smooth apertures reduce... -
Isometric Ellipses Template
Pickett$12.55Contains 27 ellipses from 1/8" to 2". Size: 57/8" x 10" x .030". -
Isometric Ellipses Template-1764075698
RapiDesign$17.15Contains 38 ellipses of 35° 16 from 1/8" to 1-9/16". Size: 6-5/8" x 11 ¼" x .030". -
Large Isometric Guide Template
Alvin Drafting$13.00Contains 12 ellipses from 2 1/8" to 4". Size: 95/8" x 1-9¾" x .020". -
Master Ellipse Template
Pickett$10.60Pickett templates have been designed to conform to the exacting demands of the professional architect, draftsperson and engineers.Features: 24 ellipses at 10 to 60 degree projections in 10 degree... -
Metric Ellipse Master Template
RapiDesign$15.10Contains: 20, 30, 40, and 50 projections. Sixty ellipses ranging in size from ¼" to 1-3/8". Size: 5" x 10 ¼" x .030".
Types of Ellipse Templates
Ellipse templates are precision drafting tools used to draw accurate elliptical shapes for technical drawings, isometric views, mechanical details, architectural drawings, and design layouts. These templates are especially useful when a drawing requires consistent ellipse angles, clean curves, and repeatable sizing.
- Single-Angle Ellipse Templates: Draw ellipses in specific drafting angles such as 10°, 15°, 20°, 25°, 30°, 35°, 40°, 45°, 50°, 55°, 60°, 65°, and 70°
- Multi-Angle Ellipse Templates: Combine several common ellipse projections on one template for flexible drafting and design work
- Small Ellipse Templates: Create smaller ellipses for detailed technical drawings, compact layouts, symbols, and precision design work
- Large Ellipse Templates: Draw larger ellipses for layouts, presentation drawings, mechanical details, architectural drawings, and oversized design elements
- Ellipse Template Sets: Provide multiple ellipse templates or size ranges for broader drafting coverage across different angles and applications
- Isometric Ellipse Templates: Create ellipses used in isometric drawing, including cylinders, holes, pipes, wheels, and rounded objects shown in three-dimensional views
- Master Ellipse Templates: Offer multiple ellipse angles and sizes on one template for professional drafting, engineering, and technical illustration
Choosing the Right Ellipse Template
When selecting an ellipse template, consider the ellipse angle, size range, and type of drawing being created. Single-angle templates are useful when a specific projection is required, while multi-angle and master ellipse templates are better for general drafting work where several ellipse angles may be needed.
Isometric ellipse templates are especially important for technical and mechanical drawings because circular objects appear as ellipses when shown in isometric view. For complete drafting coverage, many students and professionals keep both standard ellipse templates and isometric ellipse templates available.
Complete Your Drafting Workspace
Pair ellipse templates with related drafting templates and drawing tools to create accurate curves, circles, angles, and technical layouts.
Shop Circle Templates | Shop Geometric Shape Templates | Shop Drawing Compasses | Shop Drafting Triangles | Shop Drafting Scales | Shop Protractors
